Video Walls Made Easy.
Meet iBX440
SpinetiX iBX440 is the digital signage player that makes
video walls accessible to everyone.
Video Wow for Everyone
4x4K at 60 fps
Four HDMI outputs, a cutting-edge Intel® Core™ processor, the purpose-built DSOS™ operating system, and user-friendly SpinetiX ARYA™ CMS all work together to enable impressive 4x4K video walls at 60 fps while making setup easy for everyone.
Watch the video
iBX440 is the winner of the
rAVe "Best Digital Signage Media Player" and "Best New Video Wall Processor" awards at ISE 2024.
Spot-On Features
- 4x HDMI Outputs: Enables high-resolution 4x4K video walls at 60 fps
- Perfect Synchronization: Seamless display across multiple screens enabled by latest-gen Intel® Core™ processor
- Compact Design: For easy installation and management
- External Airflow Cooling: Ensures dust protection, extends player lifespan, and eliminates maintenance needs
- SpinetiX Signature: Combines robust hardware design with award-winning dedicated OS and advanced CMS for effortless video wall setup
- Designed for 24/7 use
- TAA Compliant: Meets stringent regulatory standards, ensuring compliance and premium quality
- 3-year warranty included, extendable to 5
CMS Genius.
Video Wall Magic.
SpinetiX ARYA comes standard with every iBX440 and now features a custom intuitive wizard to guide you through the setup of your video wall. Combined with powerful templates, it helps you easily set up impactful content in various video wall layouts in either vertical or horizontal mode. Now anyone can do it.
Learn more >
All Your Displays.
One Seamless Experience.
SpinetiX ARYA works as a centralized cloud solution for managing both single displays and video walls all in one place. It is that easy.
Learn more >
Beyond Video Walls.
Your Multi-Screen Powerhouse
iBX440 can effortlessly manage complex multi-screen setups – from high definition LED walls with SpinetiX ARYA to advanced custom-layout video walls, enabled by our advanced content authoring software, Elementi.
Specifications
| Connectors & Ports |
Video 4x HDMI 2.0 USB port 3x USB 3.1 10 Gbps, 1x USB 2.0 Network 2x Ethernet 1GbE, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3az. (port 2 reserved for local diagnostics) Power supply 12V DC, 84W, lockable
|
| Size & Weight |
Size Width: 7.90” / 200.8mm, height: 1.62” / 41.2mm, depth: 5.48” / 139.3mm Weight 1.8kg / 3.7lbs
|
| Operating System |
DSOS by SpinetiX Lightweight, high performance and secured operating system designed for digital signage enabling by default SpinetiX ARYA CMS OS Security Cryptographically signed firmware packages, Secure Boot Optional features Different optional modes of use to be activated on top of the built-in SpinetiX ARYA cloud based service
|
| Displays |
Video Up to 4 fully synchronized outputs, 4K UHD (3840x2160), 1080p (1920x1080), custom resolutions, etc. Audio Up to 8 channel digital audio over HDMI, stereo analog output (line level) Control Serial port (advanced protocols, accessory required)
|
| Storage |
Internal Industrial 128 GB SSD External Hard disk (via USB 3.1)
|
| Characteristics |
Processor Intel® Core™ I5-1145G7E Memory RAM: 2x 8GB DDR4-3200 Operating temperature Ambient range 32 - 113°F / 0 - 45°C, Relative humidity 10-90% non-condensing Real-time clock (RTC) Accuracy ±1 min./month, battery backed Usage Commercial-grade robust, external fan design for 24/7 operation IP code IP30 Misc. Mounting brackets included
|
|
Warranty |
3 years included limited hardware warranty, extendable to 5 years |
Please note that the iBX440 would require a valid DSOS licence to activate some of the features described above. Please contact your SpinetiX representative for more information.
Engineered for Excellence.
What sets a SpinetiX player apart?
Robust Hardware
Featuring design dedicated to signage applications, our players are made to deliver content flawlessly 24/7 supporting any signage scenario.
Purpose-Built OS
Powered by DSOS – the award-winning SpinetiX purpose-built signage OS, our players offer optimal, continuous performance and enhanced security while minimizing resource use.
Powerful Content Tools
Quickly display impactful content with the award-winning SpinetiX ARYA CMS, included with all players. Scale up with our advanced content authoring software, Elementi.
.
Get Started
Make it Yours.
Where to Buy
Buying from SpinetiX is easy. In collaboration with our global partners, we deliver leading solutions to customers all over the world.
Discover All Our Players
