Video Walls Made Easy.

Meet iBX440



SpinetiX iBX440 is the digital signage player that makes
video walls accessible to everyone.







Video Wow for Everyone

4x4K at 60 fps



Four HDMI outputs, a cutting-edge Intel® Core™ processor, the purpose-built DSOS™ operating system, and user-friendly SpinetiX ARYA™ CMS all work together to enable impressive 4x4K video walls at 60 fps while making setup easy for everyone.

Watch the video



rave best video wall media player award for spinetix ibx440



iBX440 is the winner of the
rAVe "Best Digital Signage Media Player" and "Best New Video Wall Processor"
at ISE 2024.



Spot-On Features



  • 4x HDMI Outputs: Enables high-resolution 4x4K video walls at 60 fps
  • Perfect Synchronization: Seamless display across multiple screens enabled by latest-gen Intel® Core™ processor
  • Compact Design: For easy installation and management
  • External Airflow Cooling: Ensures dust protection, extends player lifespan, and eliminates maintenance needs
  • SpinetiX Signature: Combines robust hardware design with award-winning dedicated OS and advanced CMS for effortless video wall setup
  • Designed for 24/7 use
  • TAA Compliant: Meets stringent regulatory standards, ensuring compliance and premium quality
  • 3-year warranty included, extendable to 5



CMS Genius.
Video Wall Magic.



SpinetiX ARYA comes standard with every iBX440 and now features a custom intuitive wizard to guide you through the setup of your video wall. Combined with powerful templates, it helps you easily set up impactful content in various video wall layouts in either vertical or horizontal mode. Now anyone can do it.

Learn more >

video walls made easy with ibx440 and spinetix arya cms



All Your Displays.
One seamless experience.



SpinetiX ARYA works as a centralized cloud solution for managing both single displays and video walls all in one place. It is that easy.



Learn more >



Beyond Video Walls.

Your Multi-Screen Powerhouse



iBX440 is capable of effortlessly managing complex multi-screen setups – from high definition LED walls with SpinetiX ARYA to advanced custom-layout video walls, enabled by our advanced content authoring software, Elementi.





Specifications



Connectors & Ports



Video
4x HDMI 2.0



USB port
3x USB 3.1 10 Gbps, 1x USB 2.0



Network
2x Ethernet 1GbE, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3az. (port 2 reserved for local diagnostics)



Power supply
12V DC, 84W, lockable



Size & Weight



Size
Width: 7.90” / 200.8mm, height: 1.62” / 41.2mm, depth: 5.48” / 139.3mm



Weight
1.8kg / 3.7lbs



Operating System



DSOS by SpinetiX
Lightweight, high performance and secured operating system designed for digital signage enabling by default SpinetiX ARYA CMS



OS Security
Cryptographically signed firmware packages, Secure Boot



Optional features
Different optional modes of use to be activated on top of the built-in SpinetiX ARYA cloud based service



Displays



Video
Up to 4 fully synchronized outputs, 4K UHD (3840x2160), 1080p (1920x1080), custom resolutions, etc.



Audio
Up to 8 channel digital audio over HDMI, stereo analog output (line level)



Control
Serial port (advanced protocols, accessory required)



Storage



Internal
Industrial 128 GB SSD



External
Hard disk (via USB 3.1)



Characteristics



Processor
Intel® Core™ I5-1145G7E



Memory
RAM: 2x 8GB DDR4-3200​​​​​​​



Operating temperature
Ambient range 32 - 113°F / 0 - 45°C, Relative humidity 10-90% non-condensing​​​​​​​



Real-time clock (RTC)
Accuracy ±1 min./month, battery backed​​​​​​​



Usage
Commercial-grade robust, external fan design for 24/7 operation​​​​​​​



IP code
IP30​​​​​​​



Misc.
Mounting brackets included





Warranty



3 years included limited hardware warranty, extendable to 5 years

Please note that the iBX440 would require a valid DSOS licence to activate some of the features described above. Please contact your SpinetiX representative for more information.



Engineered for Excellence.

What sets a SpinetiX player apart?



Robust Hardware


Featuring design dedicated to signage applications, our players are made to deliver content flawlessly 24/7 supporting any signage scenario.

Purpose-Built OS


Powered by DSOS – the award-winning SpinetiX purpose-built signage OS, our players offer optimal, continuous performance and enhanced security while minimizing resource use.

Powerful Content Tools


Quickly display impactful content with the award-winning SpinetiX ARYA CMS, included with all players. Scale up with our advanced content authoring software, Elementi.
